KJ150 Van Mounted Crane (1M Boom)
SKU: KJ150/1
| Max Working Load (MWL) | 150 kg |
|---|---|
| Boom Reach | 1011 mm |
| Weight | 24 kg |
Key Features
- Ideal for lifting items such as compressors, pumps and light plant equipment
- 1-metre boom plus 2 pivot points means the operator can carry out lifts within a 2-metre diameter
- Overload device – will not lift more than MWL protecting the operator and vehicle.
- Low crane weight of approximately 24kg
- Van Pillar – Dependant on vehicle (average 9kg)
- Compact design maximising vehicle floor space
- Fully demountable – can be deployed on other vehicles or removed altogether, therefore, maintaining maximum fleet flexibility
- Can be re-fitted to new or replacement vehicles
- Easy to operate with wander lead control
Description
The KJ150 is a lightweight, knuckle-joint crane that lifts up to 150kg. It is the perfect solution for those who need to lift less than the standard 250kg knuckle-joint range. The unique Penny Engineering design allows users to maximise reach but still load down the centre line of the load area of the van.
The KJ150 is a very popular crane for vans in the telecoms and utilities industries, it is used to lift compressors, pumps and light plant equipment on and off their vehicle
Downloads
Product Specific
Electric SwingLift Cranes
Add-Ons/Options
- 12v or 24v operation from the vehicle battery
- Radio remote control
- Cranked hinge available allowing even greater flexibility
- Extra rope length – 9m/30′
- Battery protection
- Lifting accessory kit
- Stabiliser/outrigger pads
- Manual stabiliser legs
- Powder-coated paint finish
