PH230 2.2tm Flatbed Mounted Crane
SKU: PH230
| Max Working Load (MWL) | 1800 kg |
|---|---|
| Boom Reach | 5200 mm |
| Weight | 225 kg |
Key Features
- Crane Weight 225 kg to 275 kg
- 2.2tm / 22 kNm rated hydraulic crane
- Standard outreach from 3.20 to 4.20m
- 360° slewing rotation
- ECI – Electronic Capacity Indicator
- 4 function valve bank
- Motor pump kit with 11 lt. oil tank for electro-hydraulic versions 12/24V (along with battery connection cables)
- 15 lt. oil tank for H (PTO – Power Take Off) version
- Fitting kit inc. tie bolts set, nuts & lock nuts, spare grease cartridge for slewing worm gear
Description
The PH230 is the lightweight crane that packs a heavyweight punch. Boasting a self-weight from only 225kg, a max working load of up to 1800kg and optional boom outreach of 5.2 metres – the PH230 is a popular choice for those who need to lift larger loads.
Downloads
Product Specific
PH230.2 Specification
PH230.3 Specification
PH230 Technical Data
PH230 Parts
PH Crane Flyer
PH Installation Manual
ECI – Rated Capicity Indicator: Instructions
LLC – Load Limiting Cell: Instructions
LME04 – Rated Capacity Device: Instructions
SCU – Stability Control Unit Instructions
PH230 Operating & Maintenance Manual
Add-Ons/Options
- Crane base with 1 hydraulic and 1 mechanical stabiliser (fixed or tilting)
- Crane base with 2 hydraulic stabilisers (fixed or tilting)
- ECI, LLC or LME04 & SCU monitoring devices
- Slew limit kit
- Boom in transit warning kit
- Stabiliser/outrigger pads
- Micro-switch kit to confirm leg stowage
- 3 – 4 function proportional remote control (by cable or radio)
- 500kg hydraulic winch (for H versions only)
- Stabiliser leg extensions
- Marinised paint finish
- Flashing light kit for remote control
